Varitrans metalline

Movable glass wall system with flush-recessed single-point fixings of stainless steel – offering exceptional visibility and an enhanced feeling of spaciousness. This elegant construction eliminates the need for frame profiles thus further augmenting the modern all-glass look. The various elements and extras available in the Varitrans metalline range offer great scope for individual layouts and modes of usage.

  • Super-stable design (steel-aluminum construction)
  • Sound reduction ratings up to Rw 59 dB with optimized profiles and seals
  • Low VOC emissions sets new standards
  • The combination with Variflex glass elements offers many design options

Elegance epitomised

The main feature of the Varitrans Metalline is its single-point fixings of stainless steel recessed flush with the glass The glass mounting and locking devices are integrated in one functional unit A lock detent is included to prevent unauthorised access This elegant construction eliminates the need for frame profiles, thus further augmenting the modern all-glass look.

Easy to operate – whether manual or fully automatic

There are two operating systems available to suit your effort-saving requirements: standard manual operation, or our premium fully automatic control option ComfortDrive. This fully automatic control system moves the panels at the push of a button, ensuring effortless, fast positioning at speeds of up to 250 mm/s.

Sound advice right from the initial planning phase

Whether for a new building, a conversion or a refurb, the decision in favour of a DORMA Hüppe movable wall system will ensure you reap the benefits of high product quality combined with the advisory expertise of our experienced, helpful staff. We will assist you in your specific project with individual support and advanced architectural tools to ensure a fully integrated approach to planning, design and installation.

Features

  • Open, natural aesthetic elegance
  • Elegant design with flush-recessed single-point fixings of stainless steel
  • Flexible modular kit system
  • Manual and fully automatic control
  • Sustainability included: Covered by environmental product declaration (EPD) to ISO 14025 and EN 15804

Technical Data

  • Clear height: max. 4,000 mm
  • Element widths: max. 1,300 mm
  • Glass: 10 and 12 mm TSG
