Variflex 100

It’s the clever technology that makes the Variflex such a special partition system. Its success derives from the clever combination of a multitude of intelligent details. Different panel types allow adaptation to a wide range of applications. The track systems are so versatile that a partition can be readily fitted into even a small space. And the sophisticated panel design of the DORMA Hüppe Variflex ensures impressive acoustic insulation – a convincing concept based on a truly “sound” system.

  • Super-stable design (steel-aluminum construction)
  • Sound reduction ratings up to Rw 59 dB with optimized profiles and seals
  • Low VOC emissions sets new standards
  • The combination with Variflex glass elements offers many design options

Partition layout adaptable to any room geometry

With its variety of panel types the Variflex system can be tailored to almost any class of application in the most diverse areas of commercial usage. Whether to meet exclusive design requirements or incorporate doors or different window types DORMA Hüppe Variflex offers the right solutions for all kinds of detail requirements.

Operating convenience from manual to fully automatic

There are three operating systems available to suit your effort-saving requirements: standard manual operation semi-automatic operation (ComforTronic) or our premium fully automatic control option (ComfortDrive). This fully automatic control system moves the panels at the push of a button ensuring effortless high-speed positioning with precision sealing strip extension to brace the panels in suit.

Sound advice right from the initial planning phase

Whether for a new building a conversion or a refurb the decision in favor of a DORMA Hüppe partition system will ensure you reap the benefits of high product quality combined with the advisory expertise of our experienced helpful staff. We will assist you in your specific project with individual support and advanced architectural tools to ensure a fully integrated approach to planning design and installation. Emissions test acc. to latest test criteria reached reference value only TVOC 57 μg/m³

Features

  • Super-stable design (steel-aluminium construction)
  • Low specific weights per unit area for easy handling and obvious structural advantages.
  • Sound reduction ratings up to Rw 59 dB with optimised profiles and seals.
  • Variflex and Variflex Glass can be combined for a partition that offers both sound insulation and transparency
  • Manual, semi-automatic and fully automatic control
  • Smoke control certificate to EN 1634-3 as standard
  • Sustainability included: Covered by environmental product declaration (EPD) to ISO 14025 and EN 15804

Surface Finishes

Standard

  • Classic Collection: Melamine and HPL (high-pressure laminate)

Premium

  • Design Collection
  • Functional Collection
  • Other surface finishes

Technical Data

  • Clear passage height: max. 14,500 mm
  • Panel width: max. 1,250 mm
  • Sound insulation

Variflex 100

Rw in dB 39 46 49 52 55 57 59
Weight kg/m2 30 31 40 40 48 48 56

Variflex Glass

Rw in dB 47 50 52
Weight kg/m2 49 45 56

Specification

Download
