Varitrans ComfortDrive

The Varitrans ComfortDrive model with advanced bus technology offers the ultimate in premium-grade control. This fully automatic control system moves the panels at the push of a button ensuring fast positioning at speeds of up to 250 mm/s. Aside from the standard functions you can also programme in individualised positions and personnel control modes.

  • Super-stable design (steel-aluminum construction)
  • Sound reduction ratings up to Rw 59 dB with optimized profiles and seals
  • Low VOC emissions sets new standards
  • The combination with Variflex glass elements offers many design options

Customised control and programming functions

Fully automatic operation from a control panel, Premium touchpanel display (optional), and soon also to be operable from a smartphone app. In addition to the standard functions "Open", "Close" and "Stop", special positions such as "Personnel" (1-panel open), “Gapped" and other freely selectable arrangements can be individually programmed and implemented.

Inherently safe if obstructed

It’s the clever technology that makes the Varitrans such a special movable wall system. Its success derives from a smart combination of a multitude of intelligent details. The integrated monitoring function in the ComfortDrive system stops and reverses the partition on contact with an obstruction.

High travel speed

Enhanced convenience thanks to rapid opening and closing action. The fully automatic ComfortDrive smart control system moves the Varitrans panels into position at speeds of up to 250 mm/s.

Features

Technical Data

  • Clear height: max. 4,000 mm
  • Element widths: max. 1,300 mm
  • Up to 30 elements and track lengths up to 50 m possible
  • Straight, segmented and curved track configurations possible
  • Max. element weight: 250 Kg
