Variflex 85

The newly developed design exhibits an exceptionally high degree of imperviousness complemented by optimised profiles and sealing strips to produce outstanding sound reduction values of up to Rw 58 dB. And with a wall thickness is just 85 mm the weight per unit area is also significantly reduced bringing both handling and structural benefits.

  • Super-stable design (steel-aluminum construction)
  • Sound reduction ratings up to Rw 59 dB with optimized profiles and seals
  • Low VOC emissions sets new standards
  • The combination with Variflex glass elements offers many design options

Variflex 85– the future of room division

The lightest of sound-insulating movable wall systems for flexible room assignment better sound insulation achieved with a thinner partition wall – a challenge impressively met by Variflex 85.

Space savings in the parking area

More room with 12 percent less wall thickness. You save space – and space is expensive. With the flexible movable wall system Variflex 88, parking areas, stacking tracks and niches can be made smaller to improve overall spatial efficiency.

Significantly reduced specific weight per unit area

Variflex 85 reduces the load: Right at the planning stage, the reduced weight means less stringent structural requirements. And the handling of the elements in day-to-day operations also requires less effort.

Features

  • Super-stable design (steel-aluminium construction)
  • Low specific weights per unit area for easy handling and obvious structural advantages.
  • Sound reduction ratings up to Rw 58 dB with a wall thickness of just 88 mm plus optimised frame profiles and seals.
  • Manual, semi-automatic and fully automatic operation
  • Space savings in the stacking/parking area
  • Smoke control certificate to EN 1634-3 as standard
  • Tested by Fraunhofer IBP (Institute for Structural Physics)
  • Sustainability included: Covered by environmental product declaration (EPD) to ISO 14025 and EN 15804

Surface Finishes

  • Classic Collection: Melamine

Technical Data

  • Clear height: max. 3,000 mm
  • Element widths: max. 1,100 mm
Rw in dB 41 46 53 56 58
Weight kg/m2 23 24 32 41 49

Specification

Download
